LWD 2325
Interior light, rectangular

Lamp type: LED

Technical data

LED light
yes
Light category
interior
Light group
HOR 66
Luminous flux
white LEDs 720 lm red LEDs 19 lm
Colour temperature
5000 K
Supply voltage
12/24 V
Power rating
white LEDs 5 W red LEDs 0,7 W/1,4 W (12 V/24 V)
Cable
3x0,5 mm2; cable length 0,5 m
Ingress protection rating
IP 65
LED quantity
6
Operating temperature range
from -30°C to +50°C

Download

Interior light, rectangular LWD 2325 (technical drawing) 1 (interior-light-rectangular-lwd-2325-technical-drawing-1.ZIP)
Download
Page content (lwd-2325.ZIP)
