LD 3171
Marker light Dragon

LD 3171 is a three-function marker lamp that comes with a flexible hanger and compact dimensions. It is specifically designed for mounting on the left side of the vehicles, ranging from small trailers to trucks and trailers.

The lamp operates on a universal voltage of 12/24 V and is characterized by low power consumption. Only branded diodes are used for production, which definitely distinguish the quality of lighting and attractively emphasize the outline of a moving vehicle.

Lamp functions:

– rear position light (red light color) – 6 diodes
– front position light (white light color) – 6 diodes
– side marker light (orange light color) – 4 diodes

Product is fully hermetic (ingress protection rating IP 68), and the operating temperature range is from -30 degrees C to +50 degrees C.

This product will meet the expectations of even the most demanding users who are looking for reliable and durable solutions for their vehicles.

Technical data

Light group
HOR 134
LED quantity
16
Light category
marker
Rear position light
yes
Supply voltage
12/24 V
Power rating
1,9 W
Operating temperature range
from -30°C to +50°C
Cable
2×0,75 mm2; cable length 0,6 m
Side marker light
yes
Side
left
Front position light
yes
LED light
yes
Ingress protection rating
IP 68

Download

Marker lamp HOR 134 (drawings ext. 02) (marker-lamp-hor-134-drawings-ext-02.ZIP)
Download
Marker lamp HOR 134 (approval ext. 02) (marker-lamp-hor-134-approval-ext-02.ZIP)
Download
Page content (ld-3171.ZIP)
