LZD 3089
Rear multifunction light

LZD 3089 – is a 2-function rear lamp that will work well in various types of vehicles such as:
– forklifts;
– quads, motorcycles;
– buses;
– vans;
– sleeping cabins and spoilers;
– agricultural and construction machinery;
– lorries;
– special vehicles.

The symmetrical design allows universal installation (both on the right and left side of the vehicle).
LZD 3089 operates at a universal voltage of 12/24 V and has low power consumption.

Lamp functions:
– rear position light (1.1/2.1 W);
– rear direction indicator (1.3/2.6 W).

Thanks to the use of a special diffuser, the lamp emits clear, red NEON position light, emphasizing its shape, without blinding other road users. Despite its small size, the direction indicator is very visible even on a sunny day. Modern design and high-quality materials used in its production make it a top-class product. The mounting screws are aesthetically sealed with gaskets.

Product is fully hermetic (ingress protection rating IP 68), and the operating temperature range is from -30 degrees C to +50 degrees C.

This product will meet the expectations of even the most demanding users looking for reliable and durable lighting solutions for their vehicles.

Technical data

Light group
HOR 138
LED quantity
18
Light category
multifunction rear
Rear position light
yes
Supply voltage
12/24 V
Operating temperature range
from -30°C to +50°C
Cable
3x0,5 mm2; cable length 0,5 m
Side
universal
Rear direction indicator
yes
LED light
yes
Ingress protection rating
IP 68

Download

Multifunction light HOR 138 (technical drawings) (multifunction-light-hor-138-technical-drawings.ZIP)
Download
Multifunction light LZD 3089 (approval) (multifunction-light-lzd-3089-approval.ZIP)
Download
Multifunction light LZD 3089 (technical drawing) (multifunction-light-lzd-3089-technical-drawing.ZIP)
Download
Page content (lzd-3089.ZIP)
