LD 2733
Rear position lamp

Rear position lamp, with a holder, HOR 112, 12/24 V, red. NEON version.

Lamp type: LED

Technical data

LED light
yes
Light category
marker
Light group
HOR 112
Side
universal
Supply voltage
12/24 V
Power rating
0,8/1,7 W
Cable
2x0,75 mm2; cable length 0,45 m, flat
Ingress protection rating
IP 68
LED quantity
9
Rear position light
yes
Reflecting device
yes
Light colour
red
Operating temperature range
from -30°C to +50°C

Download

Rear position lamp LD 2733 (technical drawing) 1 (rear-position-lamp-ld-2733-technical-drawing-1.ZIP)
Download
Rear position lamp LD 2733 (homologation) 1 (rear-position-lamp-ld-2733-homologation-1.ZIP)
Download
Rear position lamp LD 2733 (technical drawing) 2 (rear-position-lamp-ld-2733-technical-drawing-2.ZIP)
Download
Rear position lamp LD 2733 (homologation) 2 (rear-position-lamp-ld-2733-homologation-2.ZIP)
Download
Page content (ld-2733.ZIP)
